Mitsubishi MR-J2S-500A Industrial Servo Drives 200VAC 5KW NEW
Specifications Of MR-J2S-500A
| Description | MR-J2S-500A is a Drives-AC Servo produced by Mitsubishi |
| Drive Type | MR-J2S AC Servo Drive |
| Voltage | 200 VAC |
| Rated Capacity | 5 KW |
| Type | Standard general-purpose AC servo |
| Modification | None |
| Options | None |
| Warranty | 1 Year |
| Condition | Original New |
| Origin of Country | Japan |
| Brand | Mitsubishi |
Descriptions Of MR-J2S-500A
The Mitsubishi MR-J2S-500A (MRJ2S500A) is a 5000W, 200V Melservo MR-J2 servo amplifier (MRJ2S500A). The two power supply inputs, the main circuit and the control circuit. The main circuit is a 3-phase and the control circuit is a 1-phase; both power supplies have like voltages and frequencies of 200 to 230VAC, but the fluctuation can oscillate between 170 to 253VAC. For the frequency, the allowable fluctuation can be ±5%. The power consumption for the control circuit is 50W.
The MR-J2S-500A servo amplifier must remain indoors or in a place that circumvents the sunlight interactions. The clime of the servo amplifier needs to stay between temperature of 32 to 131 degrees Fahrenheit or while in storage -4 to 149 degrees Celsius.
There are four ports in the MR-J2S-500A servo amplifier. Two of the ports, the CN1A and CN1B, may be optionally be utilized as a terminal block. Notwithstanding, the CN1A can also connect to a variety of Mitsubishi control modules, especially those in the FX2N series and the Q series; while the CN1B may attach to a touchscreen panel. The MR-J2S-500A servo amplifier may connect to a personal computer that contains a MR Configurator using a RS-232C communication. And the CN2 port connects to the encoder of a motor that may be applies to the MR-J2S-500A another cable can link the servo motor to the servo amplifier by its ‘U, V, W’ terminals. Above these terminals are the ‘L1, L2, L3’ which can connect to a magnetic contractor that then concatenates to a circuit breaker. Technical Specifications Of MR-J2S-500A
Part Number: MR-J2S-500A (MRJ2S500A)
Module Type: Servo Amplifier
Voltage/Frequency: 200-230VAC, 50/60Hz, 3-phase
Output Wattage: 5kW
Weight: 10.8lbs (4.9kg)
Related Parts Of MR-J2S-500A
MR-J2S-500B - Mitsubishi Melservo MR-J2 Servo Amplifier,, 5KW, 200V, SSC NETWORK (MRJ2S500B)
HC-SFS502 - Mitsubishi Melservo HC Servo Motor, 5KW (HCSFS502)
HC-RFS353 - Mitsubishi Melservo HC Servo Motor (HCRFS353)
HC-RFS353B - Mitsubishi Melservo HC Servo Motor with Brake (HCRFS353B)
HC-RFS353BK - Mitsubishi Melservo HC Servo Motor with Brake Key (HCRFS353BK)
HC-RFS503 - Mitsubishi Melservo HC Servo Motor, 5KW (HCRFS503)
HC-UFS352K - Mitsubishi Melservo HC Servo Motor with Key, 3.5KW (HCUFS352K)
HC-UFS352BK - Mitsubishi Melservo HC Servo Motor with Brake Key, 3.5KW (HCUFS352BK)
Similiar Models Of MR-J2S-500A
MRJ2S20CPEG
MRJ2S40CPEG
MRJ2S60CPEG
MR-J2S-100A-EG011
MR-J2S-500A-EG055
MR-J2S-200A-EG011
MR-J2S-350A-EG011
MR-J2S-40A-EG011
MR-J2S-60A-EG011
MR-J2S-200A-EG055
MR-J2S-200A-S011
MR-J2S-100A-S011
MR-J2S-70A-S011
MDS-B-SVJ2-01
MDS-B-SVJ2-03
MDS-B-SVJ2-04
MDS-B-SVJ2-06
MDS-B-SVJ2-10
MDS-B-SVJ2-20
MDS-B-SVJ2-07
MDS-D-SVJ3-01NA
MDS-D-SVJ3-02NA
MDS-D-SVJ3-07NA
MDS-D-SVJ3-10NA
MDS-D-SVJ3-20NA
MR-J2S-10B-S149
MR-J2S-20B-S149
MR-J2S-40B-EE085
MR-J2S-40B-EE006
MR-J2S-40B-S009U528
MR-J2S-40CP-S186
MR-J2S-40CP-S084
MR-J2S-40A-PY091
MR-J2S-40B-PY096
MR-J2S-40B-PY135
MR-J2S-40A-PQ108T022
MR-J2S-40B-S210
MR-J2S-40A-PF
MR-J2S-40CP-EG
MR-J2S-40A-EG055
MR-J2S-40A-EG011
NR-J2S-60A-PF
MR-J2S-60B-FH168
MR-J2S-60B-S041U638
MR-J2S-60B-S134
MR-J2S-60B-S030
MR-J2S-40B-PY096T018
MR-J2S-40B-PY135
MR-J2S-40B1-EH018
MR-J2S-40B1-QA112
MR-J2S-40CP1
MR-J2S-20CP1
MR-J2S-10CP1
MR-J2S-40B-QT0009U625
MR-J2S-40A-S004
MR-J2S-10A1-S017
MR-J2S-20A-S011
MR-J2S-40A-S011
MR-J2S-70A-S011
MR-J2S-100A-S011
MR-J2S-200A-S011
MR-J2S-10A-S075
MR-J2S-70CP-S186
MR-J2S-70CP-S084
MR-J2S-40CP-S084
MR-J2S-40CP-S186
MR-J2S-70CP-S259
MR-J2S-20CP-S011
MR-J2S-70CP-S011
MR-J2S-70B-T004
MR-J2S-70B-RT
MR-J2S-70B-S009U503
MR-J2S-100B-T004
MR-J2S-100B-RT
MR-J2S-70A-PM070
MR-J2S-100CP-S084
MR-J2S-100CP-S186
MR-J2S-70B-PY135
MR-J2S-70B-PY135U504
AC Servo Motor Models:
HG-KR053BJ
HC-SF81(B)
HC-SF52(B) to 152(B)
HC-SF53(B) to 153(B)
HC-RF103(B) to 203(B)
HC-UF72(B) 152(B)
HC-SFS81(B)
HC-SFS52(B) to 152(B)
HC-SFS53(B) to 153(B)
HC-SFS524(B) to 1524(B)
HC-RFS103(B) to 203(B)
HC-UFS72(B) to 152(B)
HC-LFS52(B) to 152(B)
HC-SF121(B) to 301(B)
HC-SF202(B) to 502(B)
HC-SF203(B) to 353(B)
HC-RF353(B) to 503(B)
HC-UF202(B) to 502(B)
HC-SFS121(B) to 301(B)
HC-SFS202(B) to 502(B)
HC-SFS203(B) to 353(B)
HC-SFS2024(B) to 5024(B)
HC-RFS353(B) to 503(B)
HC-UFS202(B) to 502(B)
HA-LFS502
HC-LFS202(B) to 302(B)
HC-SF702(B)
HC-SFS702(B)
HC-SFS7024(B)
HA-LFS702
Similiar Industrial Servo Motors:
HA200B-S
HA200C
HA200CB
HA200CB-S
HA200C-S
HA200NC-S
HA103NC-S
HA100NCB-S
HA100NC-S
HA100CB-S
HA100C
HA100C-KN
HA100B-S
HA100B-SSD7
HA100C
HA100CB-S
HA100C-KN
HA100C-S
Similar Products
| SGM-01A312 |
| SGM-01A312C |
| SGM-01A314 |
| SGM-01A314B |
| SGM-01A314C |
| SGM-01A314P |
| SGM-01A3FJ91 |
| SGM-01A3G26 |
| SGM-01A3G36 |
| SGM-01A3G46 SGM-A5A314-Y1 |
| SGM-01A3MA12 |
| SGM-01A3NT14 |
| SGM-01A3NT23 |
| SGM-01A3SO11 |
| SGM-01A3SU11 |
| SGM-01A3SU31 |
| SGM-01A3T012 |
| SGM-01A3TE21 |
| SGM-01ASO11 |
| SGM-01B312 |
| SGM-01B3FJ11 |
| SGM-01B3FJ12 |
| SGM-01L314 |
| SGM-01L314P |
| SGM-01U312 |
| SGM-01U3AP01 |
| SGM-01U3B4L |
| SGM-01V314 |
| SGM-02A312 |
| SGM-02A312B |
| SGM-02A312C |
| SGM-02A312-Y1 |
| SGM-02A314 |
| SGM-02A314B |
| SGM-02A314C |
| SGM-02A3B4SPL |
| SGM-02A3F J73 |
| SGM-02A3G16 |
| SGM-02A3G16B |
MORE INFORMATION
DELIVERY
Logistic partners UPS, FedEx and DHL
International delivery available
Same day dispatch from group stock
WARRANTY
All parts new are covered by Shenzhen Viyork 12 month warranty
RETURNS
No hassle returns policy
Dedicated customer support team
PAYMENT
Trade credit
We understand that credit is a necessary part of business and offer credit agreements on request, subject to status.
Payment options
We accept Bank transfers and the following methods of payment:
Western Union PayPal VISA
|
|
Mitsubishi MR-J2S-500A Industrial Servo Drives 200VAC 5KW NEW Images
|
